Wide Viewing Angle and Easy Maintenance Stage Rental LED Display for Shows
LED rental screen can be divided into multiple video screens, the display screen can be used independently, combined, and any combination to play the relevant background, and the LED screen can be displayed according to the performance needs.
And it can realize the superposition of pictures and texts, the background picture can be played by the video signal processor or the same picture can be synthesized, the character can be played, the text can be rolled or inserted, and the video screen can be moved horizontally.
Feature
1.Unique modular design
This design makes the installation and disassembly of the screen faster and more convenient, and greatly improves the work efficiency. Since the modules can be combined flexibly according to customer needs, the entire screen can be adapted to the size and shape requirements of different places. The modular design is also easy to maintain and upgrade, effectively extending the life of the screen.
2.Energy saving and environmental protection design
The use of LED point lighting technology greatly reduces energy consumption, greatly reduces energy consumption, and saves operating costs for users. At the same time, measures such as material recycling and energy saving have been taken to effectively reduce the impact on the environment.
3.Powerful display effect and stability
The LED rental screen has the characteristics of high refresh rate and high gray scale, which can present smooth and delicate image effects, avoid flickering, smearing and other phenomena. This provides users with a more comfortable and stable viewing experience, allowing the screen to maintain good performance during long-term use.
Advantages
1. Support Curved Installation
High precision curve Lock. Support curved installation, In order to meet the various aspects of the LED screen field. 500/1000 series led display design for Curved Installation. Curved with every 2.5° between -10°and 10°, which can make convex and concave.
2.Different Installation Way
Glory series can make hanging LED display, stacking LED display, wall amounted LED display, right angle LED display etc.
3.Outdoor IP65 waterproof protection
The Glory Series designed to perform in all kinds of outdoor and indoor environments. Earning an IP65 Protection Rating, the dust-tight enclosure of the glory series works to protect the LED video wall display in outdoor installations.
Parameters
| | Giant 2.9mm | Giant 3.91mm | Giant 4.81mm |
| Pixel Pitch | 2.976mm | 3.91mm | 4.81mm |
| Pixel Configuration | SMD1415 | SMD1921 | SMD1921 |
| Pixel Density | 86,016 pixels/m2 | 65,536 pixels/m2 | 43,264 pixels/m2 |
| Module Dimensions(W x H) (mm) | 250 x 500 | 250 x 250 | 250 x 250 |
| Panel Dimensions (mm) | 500 x 500 x 80 500 x 1000 x 80 | 500 x 500 x 80 500 x 1000 x 80 | 500 x 500 x 80 500 x 1000 x 80 |
| Modules Per Cabinet (W x H) | 1 x 2 | 1 x 2 | 1 x 2 |
| Module Resolution | 168 x 84 | 128 x 64 | 104 x 52 |
| Cabinet Resolution | 168 x 168 | 128 x 128 | 104 x 104 |
| Panel Material | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum |
| Weight per Cabinet | 7.5kg | 7.5kg | 7.5kg |
| Digital Processing | 16bit | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 |
| Average Power Consumption | 200 W /Sqm | 200 W /panel | 200 W /panel |
| Max Power Consumption | 650 W /Sqm | 650 W /panel | 650 W /panel |
| Brightness | >5,000 nits | >5,000 nits | >5,000 nits |
| Refresh Rate | >3,840Hz | >3,840 Hz | >3,840 Hz |
| Vertical Viewing Angle | 160° | 160° | 160° |
| Horizontal Viewing Angle | 140° | 140° | 140° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front | Front | Front |
| IP Rating (Front/Rear) | IP 68 | IP 68 | IP 68 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Scan Method | 1/21 Scan | 1/16 Scan | 1/13 Scan |
